Combined fan nozzle design characteristics
TP type fan spray nozzle can provide high impact liquid column flow or fan-shaped spray.Jet Angle between 0 ° to 110 °.
The nozzle spray of uniform distribution, droplet size small to medium.When need several overlapping nozzle jet, a specially designed gradually covered with pointy edges makes the injection area.All TP nozzle is highly processed, so as to provide an accurate flow rate and spray Angle.Internal channel of the nozzle hole cut to protect from damage.Design features include without blocking port to reduce congestion.TP nozzle possesses the advantages of the system, such as interchangeable nozzle spray, filters and other components.
The general application
Metal cleaning and processing
Spray coating
Remove oil stains and rinse
Parts cleaning
Spray cooling
Pressure washing sand, coal and stone washing
6051 type filter
6051 type filter main body made of stainless steel processing, with a stainless steel mesh, screen mesh size is 50, 100 and 200.
